| Hardware Specifications |
| CPU | Amlogic S912 64 bit Octa core ARM Cor tex-A53 CPU up to 2 GHz |
| GPU | ARM Mali-T820MP3 GPU up to 750MHz (DVFS) |
| SDRAM | 3GB DDR4 |
| FLASH | 32GB EMMC Flash |
| WiFi | Built in 2.4G/5G WiFi Support IEEE 802.11 a/b/g/n/ac |
| BT | BT 4.0 |
| LAN Ethernet | 10/100M/1000M RGMII |
| Main Features |
| OS | Android 7.1 marshmallow |
| Video decorder | H.265 4K @60fps 10btis, VP9 Profile 2, H.264 4K @30fps, AVS+ 1080P @60fps |
| Video encorder | H.264 1080P @60fps |
| HDR | HDR 10, HLG HDR |
| KD Player | KD 17.0 version |
| DRM | Optional :Microsoft Playready,Verimatrix ,Google Widevine Level1 |
| Supported:Google Widevine Level3 |
| Decoder format | HD MPEG1/2/4,H.265/HEVC , HD AVC/VC-1,RM/RMVB,Xvid/DivX3/4/5/6 ,RealVideo8/9/10 |
| Media format | Avi/Rm/Rmvb/Ts/Vob/Mkv/Mov/ISO/wmv/asf/flv/dat/mpg/mpeg |
| Music format | MP3/WMA/AAC/WAV/OGG/DDP/TrueHD/HD/FLAC/APE |
| Photo format | HD JPEG/BMP/GIF/PNG/TIFF |
| Network Function | Miracast,,Airplay,Skype chatting,Picasa,Youtube,Flicker,Facebook,Online movies,etc. |
| Language | Chinese , English ,Germany ,Japanese, Korea etc. 24 languages |
| OTA | Support OTA update |
| Port Specifications |
| | 1* HD output 2.0 4K*2K @ 60Hz |
| 2* High speed USB 2.0,support U DISK and USB HDD |
| 1* TF CARD Support 1~32GB |
| 1* 3.5 Phone out CVBS&L/R output |
| 1*SPDIF output |
| 1* RJ45 LAN Ethernet 10M/100M/1000M |
